Nanoneedles - Contact JBP USA at firstname.lastname@example.org or 831-419-1088 for shipping costs.
The integration of craftsmanship and technology has created this ultra-thin needle to lessen patient discomfort during needling and to minimize hemorrhage and swelling.
Pain and bleeding are successfully reduced during needling by an ultra-thin walled needle which lessens friction resistances by a special process of Micron Sharpness.
It makes possible to inject high viscosity solutions with extra fine needles.
• Placenta injection
• Botox injection
• Collagen injection
• Hyaluronic acid injection
• Local anesthetics
Features of JBP Nanoneedle
ULTRA-THIN WALLED, EXTRA FINE, MICRO POLISHING TECHNOLOGY
|• Less pain & swelling
• Little bleeding
• Invisible injection marks
• Injectible for high
• Viscosity solution
Comparison of inner and outer diameters between JBP Nanoneedle and conventional needle
|Gauge||JBP Nanoneedle||Conventional needle|
|Outer Diameter||Inner Diameter||Outer Diameter||Inner Diameter|
|34G||0.20 mm||0.10 mm||-||-|
|33G||0.26 mm||0.16 mm||0.26 mm||0.10 mm|
|30G||0.30 mm||0.20 mm||0.30 mm||0.15 mm|
|27G||0.40 mm||0.30 mm||0.41 mm||0.21 mm|
|25G||0.50 mm||0.40 mm||0.51 mm||0.26 mm|
Comparison of injection marks between JBP Nanoneedle and a conventional needle
